Rock Wool

ABM-SR-MS80

ABM-SR-MS80 is a semi-rigid board made from basalt and dolomite with better thermal, acoustic performance. It can be supplied with aluminium foil, aluminium glass cloth or glass cloth.

Standard Specification
Product Properties
Product Application
Authenticity Verification

Product Type

ABM- SR- MS80

Nominal Density

80 kg/m3

L x W*

1200x600mm,1000x600mm

Thickness

50mm,100mm

*Other size and thickness are available on request

Properties

Value

Unit

Standard

Thermal Conductivity Coefficient

10℃

0.034

W/(m•K)

EN 12667,

ASTM C518

GB/T 10295

70℃

0.040

Fire Classification

Non- combustible

--

IMOA.799(19)

ASTM E136

Max Service Temperature

Pipe 650℃

Facing 80℃

ASTM C411

Melting Point

≥1000


Water Vapor Absorption

≤1.0

%

ASTM C1104M

Sound Absorption

αw=0.8

IS0 354

ISO11654

Facings

ALGC(AG1)

GC( EG2)

Reinforced alu foil(AL3)

--

IMO A. 653(16)

Low flame- spread

Environment

Asbestos free, no CFCs、HCFCs or HFCs

---

---

ABM-SR-MS80 is designed for high requirements on comfort,thermal and sound insulation

Optional Facings

ABM has prepared a variety of facings for different products. In most cases, these facings can protect the product and enhance its performance. Customers can choose the facing base on personal demands.

For More Details
  • Glass cloth (EGF-20210) ~210 g/m²

    The EGF-20210 is strong enough to protect insulation materials and prevent the dust spread to the environment with its high density

  • Aluminium Glass Cloth (AG-10701) ~118 g/m²

    AG-10701 is composited with Aluminium foil and glass cloth, has good tensile strength, dust-free and nice outlook.

  • Aluminium Foil(Al-30150) ~104 g/m²

    AL-30150 is a reinforced aluminum surface can provide the best solution on vapour barrier. It can protect the insulation materials and steel from vapour which will damage the insulation properties and cause the corrosion.
