Rock Wool

ABM-SR-MLM120

ABM®Marine Lamella Mat(MLM series) is made of lamellas cut from slabs in the length direction attaching with some facing materials such as glass tissue, aluminium foil or aluminium glass cloth(ALGC). The majority of the fibers are perpendicular to the facing.

Standard Specification
Product Properties
Product Application
Authenticity Verification

Products Type

MLM120

Nominal Density,kg/m3

120

Thickness*,mm

25, 50, 75,100

Size(LxW)* , mm

1820×605, 2000×1200

*Other size or density may be available on request.

Properties

Value

Unit

Standard

MLM 120



Thermal Conductivity

10℃

≤0.038



W/(m • K)

GB/T10295

EN 12667

ASTM C518

70℃

≤0.049

Fire Classification

Non-combustible for lamella

Low- flame spread for facings

--

IMO A.799(19)

IMO A. 653(16)

Max Service Temperature

650℃ for lamella

80℃ for facings



ASTM C411

Melting Point

≥1000

--

Water Repellent*

≥99

%

GB/T 10299

Moisture Absorption*

≤0.02

Vol%

ASTM C1104M

Compression Strength

30

kpa

EN 826

Environment

Asbestos free, no CFCs, HCFCs, HFCs

--

--

Other properties conform to GB/T 11835-2007 or JIS A9504-2011;

*Refer to water repellent products only.

ABM-SR-MLM120 is not only very flexible but also with good compression strength , can be easily installed on pipes, ducts, tanks and other curve surfaces.

Optional Facings

ABM has prepared a variety of facings for different products. In most cases, these facings can protect the product and enhance its performance. Customers can choose the facing base on personal demands.

For More Details
  • Glass cloth (EGF-20210) ~210 g/m²

    The EGF-20210 is strong enough to protect insulation materials and prevent the dust spread to the environment with its high density

  • Aluminium Glass Cloth (AG-10701) ~118 g/m²

    AG-10701 is composited with Aluminium foil and glass cloth, has good tensile strength, dust-free and nice outlook.

  • Aluminium Foil(Al-30150) ~104 g/m²

    AL-30150 is a reinforced aluminum surface can provide the best solution on vapour barrier. It can protect the insulation materials and steel from vapour which will damage the insulation properties and cause the corrosion.
